LWDAnalyser Updates

Details of new release Version 4.8.4.0

(05/2/2025)

• Bug fixed where the Rolling Mean was shown when less than 5 points where measured

Details of new release Version 4.8.3.0

(28/1/2025)

• The software now requires the user to select a material type when Other is chosen in the load criteria option in the report settings

Details of new release Version 4.8.2.0

(27/1/2025)

• Software now states Compliant or Non- compliant instead of Pass or Fail • The software will show a reminder to renew your subscription, indicating the number of days left, when it is less than 30 days from expiring

Details of new release Version 4.7.1.0

(10/1/2025)

• Data fixes to Prima 100 files with a variable sample rate, with new tracking feature when corrections are made to files • Upgraded licence registration control

Details of new release Version 4.6.2.0

(25/09/2023)

• Users can now load MiniDyn LWD files (.dynz) directly into the software • Weather information recorded by users during collection now correctly copies to reporting module • New simpler process to renew licence registration

Details of new release Version

4.5.10.100 (12/03/2023)

• Bug fixed which produce out of memory error

Details of new release Version

4.5.6.100 (1/03/2023)

• New improved map sevice • User settings automatically restored when software is updated

Details of new release Version

4.5.3.100 (24/11/2022)

• New map sevice update • New tool to enable users to rapidly select different drops to be analysed at each measurement location

Details of new release Version

4.4.10.100 (03/10/2022)

• Bug fixed with Dynatest sessions not correctly coping over the plate radius

Details of new release Version

4.4.9.100 (28/09/2022)

• New update includes the following o Individual or multiple sessions can now be loaded when Dynatest LWD data is imported into the software. o Updated to read weather, material type and Layer information from the new version of the Dynatest mobile software. o Bug fixed when Project files were saved that not all details were saved.

Details of new release Version

4.4.8.100 (23/07/2022)

• Bug fixed where less than 5 points was not calculating the 5-point moving average

Details of new release Version

4.4.7.100 (09/05/2022)

• Bug fixed where a manually added Serial number was not displayed in the output report

Details of new release Version

4.4.3.100 (26/04/2022)

• Bug fixed which incorrectly calculated Poisson’s Ratio when loading fw2 files

Details of new release Version

4.4.3.100 (19/04/2022)

• New update includes the following o Users can include the start time within the LWD foundation certificates o The front page now includes the foundation type and class o New error log reporting tool

Details of new release Version

4.3.4.100 (07/03/2022)

• New update includes the following o Users can now load Dynatest 3032 files (.db3) directly into the software without having to convert them into excel files using Dynatest’s LWDMod software. o Software can store customisable lists of LWD Operators, Testing Standards and Testing Methods. o Users can now use the temperature data recorded by the devices or manually enter data o New updates to the output report to make it easier for the reader to understand

Details of new release Version

4.2.4.100 (13/02/2022)

• New update includes the following o Software can store multiple correlation and calibration certificates as PDFs. o Updated front page fields including customer details and unique report number. o Improved user settings with more user defined features. o Output foundation certificates now show maximum applied stress and deflection in compliance with the requirements of BS 1924:2.

Details of new release Version

4.1.13.100 (29/11/2021)

• New update includes the following o Report template adjusted to fit dates and GPS data into output report. o Fixed bug where “notes” were not appearing when Dynatest LWD files were loaded.

Details of new release Version

4.1.11.100 (19/11/2021)

• New update includes the following o A new Map tool to enable users to adjust points and add additional information to the Map within the Report Generation Tool. o Users can now add their Annual Correlation Certificate, Calibration Certificate and UKAS logos. FWDAnalyser Updates

Details of new release Version 1.4.10.0

(13/11/2024)

• Fix bug where f25 file formats, without GPS data, where not loading.

Details of new release Version 1.4.9.0

(27/04/2023)

• Fix bug where the software crashes when loading another file when the user has previously chosen to report the data as a normalised plot with a cumsum plot.

Details of new release Version 1.4.8.0

(27/03/2023)

• A new version of the software has been released which includes a new F25 file reader. A cumsum plot is now shown and is included in the output reports, if selected by the user.

Details of new release Version

1.2.240.0 (17/10/2021)

• A new version of the software has been released which includes the ability for the user to produce Deflection Profile plots of F20 files from a Falling Weight Deflectometer. The temperature data is condition formatted to the requirements of CS229 as well showing the user positions of where the measurements have been taken and enabling these to plotted in the output report. FWDReader Updates

Details of new release Version

1.0.4.100 (17/10/2021)

• This software can extract the information from a FWD files from SWECO’s Falling Weight Deflectometer machine and can be loaded into the FWDAnalyser software.
